Apraksts

Part Number SOLMOZARTFLR
LED Light sources 16 CREE®
Pixels per fixture 1, 4, or 16
DMX Channels per fixture 3, 4, 12, 16, 48, or 64
Fixtures per Drive Output 8 max. in Normal Mode
5 max. in HiPower Mode
Beam Spread 36°
Colour LEDs RGBW
Average colour wavelength
(manufacturer rated)
Red: 620-630 nm
Green: 520-530 nm
Blue: 450-460 nm
Refresh rate 1200 Hz
Intensity Control 8bit
Control DMX-512A, RDM
DC Power 48V
Power Consumption 25W
Cooling Convection
IP Rating IP54
Operating Temperature -20°C to +40°C
Control/Power Connectors In/Out – Amphenol Sensor M12
Unit Dimensions (HxWxD) 120 x 120 x 49 mm [4.7 x 4.7 x 1.9 in]
Shipping Dimensions (HxWxD) 127 x 165 x 172 mm [5 x 6.5 x 6.75 in]
Unit Weight 1.0 kg [2.20 lb]
Shipping weight 1.1 kg [2.45 lb]
